Billet Homogenizing Furnace, using Diesel Burner
Overview
Contact Us
Diesel is the one of the main fuels for industrial furnace. Diesel fuel is cleaner compared to heavy oil. It is safer compared to heating electrically and costs cheaper. The homogenizing furnace using diesel burner supplied by us has specifications include 10 tons, 20 tons, 30 tons, 40 tons and 50 tons. We can provide batch aluminum rod homogenizing furnace, continuous aluminum rod homogenizing furnace or heat flow aluminum homogenizing furnace according to our customers processing needs.
In April 2015, a customer from Vietnam purchased the custom-made 20 tons homogenizing furnace from us and it operates normally until today.
Parameters| Items | Technical Parameters |
| Tonnage | 20 tons |
| Production | 20 tons |
| Maximum operate temperature | 570℃ |
| Number of controlling area | 3 |
| Number of draught Fan | 3 |
| Power of draught Fan | 32/42KW |
| Number of nozzles | 6 |
| Total power of homogenizing furnace using natural gas | 180KW |
| Time taken for heating at the aluminum rod surface to achieve homogenization temperature | 4 hours |
| Dimensions (Length x Width x Height) | 8300X6600X5200 |
| Cooling method | Air-cooled + water-cooled |
Founded in 2008, Huitai Technology manufactures engineered equipment for aluminum melting, casting and billet-processing operations. Equipment is configured according to the customer’s production requirements, plant conditions and existing line, supported by fabrication, machining, welding, assembly and control-system integration capabilities.
